Forklift Starters
Forklift Starter - The starter motor nowadays is normally either a series-parallel wound direct current electric motor that has a starter solenoid, that is similar to a relay mounted on it, or it can be a permanent-magnet composition. Once current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is positioned on the driveshaft and meshes the pinion with the starter ring gear which is found on the engine flywheel.
Once the starter motor begins to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid consists of a key operated switch which opens the spring assembly so as to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just a single direction. Drive is transmitted in this particular method via the pinion to the flywheel ring gear. The pinion continuous to be engaged, like for instance for the reason that the driver fails to release the key once the engine starts or if the solenoid remains engaged because there is a short. This actually causes the pinion to spin separately of its driveshaft.
This aforementioned action prevents the engine from driving the starter. This is an essential step as this kind of back drive will allow the starter to spin really fast that it could fly apart. Unless modifications were made, the sprag clutch arrangement would preclude using the starter as a generator if it was used in the hybrid scheme discussed earlier. Typically a regular starter motor is meant for intermittent use which would preclude it being used as a generator.
Therefore, the electrical components are designed to function for just about less than 30 seconds so as to prevent overheating. The overheating results from very slow dissipation of heat due to ohmic losses. The electrical components are designed to save weight and cost. This is truly the reason nearly all owner's guidebooks meant for vehicles recommend the operator to pause for a minimum of 10 seconds after each ten or fifteen seconds of cranking the engine, if trying to start an engine that does not turn over immediately.
During the early part of the 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Before that time, a Bendix drive was utilized. The Bendix system works by placing the starter drive pinion on a helically cut driveshaft. As soon as the starter motor starts spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, thus engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to exceed the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
In the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design that was made and launched in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights inside the body of the drive unit. This was a lot better as the typical Bendix drive used in order to disengage from the ring once the engine fired, although it did not stay functioning.
As soon as the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, for example it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be prevented prior to a successful engine start.
